This is a Biometric fingerprint lock with mechanical keys, which means no worry the battery. Support with TTlock APP, also compatible with Alexa/ Google Home/ SmartWatch.

Features:

• TTLock APP manages one-time password / time-limited password
• Support computer terminal management, remotely send password management, remotely authorized users to unlock and unlock records locally
• Unlock record cloud update real-time remote door opening
• Remotely change the password in the lock
• Remotely delete fingerprint/door card users
• External Power Supply
• In case of battery die, mechanical keys and external power are provided to unlock the door then replace the batteries
• YRHAND Model: YRHAND G01PL



Specification：

• Material: Zinc Alloy
• Unlock method: App/Bluetooth, Fingerprint, Passcode, key.

Package Included：

• 1 x smart lock
• 1x 60/70mm adjustable backset latch
• 1x latch box and strike plate
• 2 x mechanical keys
• 1x installation crews bag

Description

Door Bell Ring Function When Door Bell Ringing，you can know the visitor comes.No need to buy a extra door bell.	Private Button Function NX1 Plus Smart lock provides enhanced security when you enable private lock from inside, Only admin user can access. Turn on the Private Button ,the lock can not unlock and the room can not access.. Turn off the Private Button,the lock can unlock and the room can access.	Emergency Power When lock power runs out, you can charge by connecting a power bank via USB cable.

NX1 Plus is the updated version for NX1 Model.It has new functions ,such as Fingerprint Reader Handle ,Doorbell, Private Button, Built-in Alarm Speaker.

It will offer more functions and convenient for users.

Support Virtual Password

Ensures that strangers can’t steal your password by watching you nearby when you enter the password. Type random digits and can still gain access as long as One correct password.

High security

The black box can not easily to unlock the smart lock.It keep Highly security for your life.

Receive Real-Time Notifications

Receive notifications, wherever you are, and check app record any time .

You will always know who entered, when and how, all records of opening will be sent to the administrator’s TT LOCK APP.

Send Ekey to others

Use the TTlock app to share access code with people. Access can be permanent,time One time temporary or custom d and recurring Passcode anytime.

Remote Control By Hub And Also Compatible With Smart Devices

Work with G2 Wifi Gateaways（need to buy extra .）Generate passcode remotely and share it to your visitors.. you can lock/unlock your smart door anywhere anytime, set up codes remotely and check real-time access logs.

It can use voice control via hub that will compatible with Amazon Alexa and Google Home ，smart watch devices ，ect.

This NX1 Plus Smart lock is updated version of NX1，it has new design change and add more functions:

1.Add one semiconductor fingerprint identification reader in the lock front handle.

2.Add door bell in the panel keypad, you can save a extra door money and also can know other come easily when bell is ringing.A beautiful sound replaces the door knocking noise.

3.Add manual private button in the rear panel，offer more privacy for daily life and business time.

4.Add Voice alarm speaker in the rear panel, you can get voice prompt and know the lock status easily.

Spec：

Unlock method: Fingerprint,IC Card,passcode,APP,mechanical key

User Capacity：Card:200 group/password:150 roups/Fingerprint: 100 groups, one admin

App name: TTLock

Material: Acrylic touchscreen pad, stainless steel reversible handles

Available color: Black Nickel

Panel Sizes: L 234(mm)*W 66.8(mm)

Door Thickness (ideal range) - 38-55 (mm)

Net Weight - 3 kg

Unlock time: 1~1.5 seconds

Communication: Bluetooth 4.0 above

Support system: IOS7.0 or Android 4.4 or above

Batteries life: 7000 times normal unlock(10-12 months)

Power supply: DC6V:4pcs AA alkaline batteries

Static current: ≦50uA

Dynamic current: <200Ma

Unlock time: 1-1.5 seconds

Working temperature: -0~50°C degree

Working Humidity: 10%~95%

Factory Initial Password:123456,after configuration,it will be invalid

Virtual Password:Support

Door Bell Function: Support

Alarm Warning:Support ,it has built in Alarm Speaker

Package included:

1X smart lock

1XAdjust 60mm-70mm （2-3/8 inch to 2-1/4） latch

1X Latch box and strike plate

5X Smart key cards

2X Mechanical keys

1X Installation crews bag

1X Manual

1X Borehole Diagram

Product Description

Support Virtual Password Ensures that strangers can’t steal your password by watching you nearby when you enter the password. Type random digits and can still gain access as long as One correct password.	Back Up Power You can charge the lock via usb by Powerbank when the battery run out.	Suitable for Any Season Keeps your home safe during cold winters, or hot summers.But if better, the lock installs the dorr with sheltered eaves.It can use longer time.

360° Semiconductor Fingerprint Scanner

Smart Lock correctly recognizes registered fingerprint in 1.5-2.5s .which can read faster and not easy to copy ，also have high recognition rate，more safe for daily use.

360° Fingerprint Reader

Secure Lock Button

A Updated Back Up Key hole

Easy to Install

Remote Control By Hub And Also Xompatible With Smart Devices

Work with G2 Wifi Gateaways（need to buy extra .）Generate passcode remotely and share it to your visitors.. you can lock/unlock your smart door anywhere anytime, set up codes remotely and check real-time access logs.

It can use voice control via hub that will compatible with Amazon Alexa and Google Home ，smart watch devices ，ect.

Share Ekey

Use the TTlock app to share access code with people. Access can be permanent,time One time temporary or custom d and recurring Passcode anytime.

Features:

• Perfect for homes with kids, frequent visitors, vacation rental guests, maintenance or housekeeping staff even office employee, short-term rental hosts, rental property management, and self-housing resident. You will be able to control your Deadbolt Lock with only one smartphone. Generate passcode remotely and share it to your visitors.Lock/unlock your smart door lock anywhere anytime, set up codes remotely and check real-time access logs.
• Bluetooth Access：Manage A220 Bluetooth Smart Lock from your phone when you are within Bluetooth range. Lock and unlock the door, add or remove users, control access and monitor usage - all from your smartphone.
• Fast unlock: 1~1.5 seconds unlock by IC Card, passcode, APP, wristband, mechanical key. The Doorlock make it more flexible
• Remote Control: Connect G2 wifi Gateway（hub）will support the smart door lock. It is a tool for you to open the lock with app remotely even in far distance. Even without it, you can still send passcode or ekey and give access to others to open the door, check the door opening records, and manage your keys on app. Hub is an optional tool.
• Longer Life’s pan: Both the front and back panel of this Smart Digital Door Locks are made of Aluminum, ABS, Acrylic.  A220 smart deadbolt lock requires 4 AA batteries for operation (Not Included).which use in 10000 times normal unlock (12 months)
• YRHAND Model:  YRHAND A220

Specification:

• Material：Aluminum, ABS, Acrylic
• Color：Gray./Black/Sliver
• Door Thickness: 35-55mm
• Communication：Bluetooth 4.0 BLE
• Support OS: iOS 7.0 or above, Android 4.4 or above
• Battery Life: 10000 times normal unlock (12 months)
• Power Supply: DC6v:4pcs AA alkaline batteries(battery is not included） Static Current: 45uA
• Dynamic Current :< 200mA
• Unlock Way: IC Card, passcode, APP, wristband, mechanical key
• Unlock Time:1~1.5 seconds
• Working temperature: -20~50 degree
• Working humidity:10%~95%
